Accessory TANSA LTT 313 ED Tripod Turnstile - Stainless Steel, Bidirectional, Fail-Safe, Emergency Drop Arm

Operation:

• Adjustable Manual Passage: Allows for manual adjustment of the passage to either direction.

Frame:

• Material: Single-legged frame made from AISI 304 quality stainless steel.

• Optional: Upgrade to AISI 316 quality stainless steel for enhanced resistance to corrosion, ideal for harsher environments.

Core and Arms:

• Core: CNC-machined aluminum cast core, offering strength and precision.

• Arms: Ø 40x2.5 mm polished aluminum arms for smooth operation and durability.

• Optional: Stainless steel arms for a more robust, premium finish.

Functions:

• Passage Information: Configurable to NC (Normally Closed) or NO (Normally Open) to control passage state.

• Passage Time: Adjustable to suit operational requirements.

• Memory Mode: Retains configuration settings for automatic adjustments.

• Audio Warning: Provides an audio alert when a passage occurs.

• Adjustable Passage Direction: Flexibility in controlling the flow of traffic, configurable to desired direction.

Mechanism:

• Material: Constructed with AISI 304 quality stainless steel for durability and reliability.

• Fail-Safe Feature: In the event of a power failure, the arms automatically drop to allow easy passage.

• Optional: Fail Lock feature to keep the turnstile locked during power failure for more controlled access.

Emergency Mode:

• Activation: Arms automatically drop when a signal is received from the fire detection system to facilitate emergency evacuation.

• Optional: Drop Arm feature for further flexibility in emergency situations.

Indicator:

• Direction LED Indicators: LED lights indicate the direction for passage, ensuring clear user guidance.

• Optional: Upper Lid for added visibility and aesthetic appeal.
